Cisco GLC-EZX-SM-150 Compatible 1000BASE-ZXC SFP 1550nm 150km Transceiver Module
Cisco GLC-EZX-SM-150 Compatible 1000BASE-ZXC SFP 1550nm 150km Transceiver Module
Cisco GLC-EZX-SM-150 Compatible 1000BASE-ZXC SFP Transceiver Module (SMF, 1550nm, 150KM, LC, DOM)
Cisco GLC-EZX-SM-150 compatible 1000BASE-ZXC SFP transceiver module is equipped with an LC duplex connector, which is high-performance, cost-effective, supporting 1.25Gbps data rate and 150KM transmission distance over single-mode fiber (SMF). F-tone 1000BASE-ZXC transceiver is compatible with IEEE 802.3af Gigabit Ethernet.
This compatible 1000BASE-ZXC SFP fiber optic transceiver module consists of three sections: a DFB laser transmitter, an APD photodiode integrated with a trans-impedance preamplifier (TIA), and an MCU control unit. All F-tone manufactured 1G SFP optical transceivers satisfy class I laser safety requirements.
|
Part Number |
FT-SFP-03150D |
Vendor Name |
F-tone |
|
Form Factor |
SFP |
Data Rate |
1.25Gbps |
|
Wavelength |
1550nm |
Distance |
150km |
|
Connector |
LC Duplex |
Cable Type |
OS2 SMF |
|
Transmitter Type |
DFB |
Receiver Type |
APD |
|
TX Power |
1~ 6dBm |
Receiver Sensitivity |
<-33dBm |
|
Power Consumption |
< 1W |
Modulation Format |
NRZ |
|
DDM |
Support |
Bit Error Ratio (BER) |
1E-12 |
|
Commercial Temperature Range |
0 to 70°C (32 to 158°F) |
Warranty |
5 Years |
1G Fiber SFP Model Contrast Table
|
Part Number |
FT-SFP-0301D |
FT-SFP-0302D |
FT-SFP-0310D |
FT-SFP-0320D |
FT-SFP-0340D |
|
Image |
|
|
|
|
|
|
Max. Data Rate |
1.25Gbps |
1.25Gbps |
1.25Gbps |
1.25Gbps |
1.25Gbps |
|
Wavelength |
850nm |
1310nm |
1310nm |
1310nm |
1310nm |
|
Max Distance |
550m |
2km |
10km |
20km |
40km |
|
Connector |
LC Duplex |
LC Duplex |
LC Duplex |
LC Duplex |
LC Duplex |
|
Media |
MMF |
SMF/MMF |
SMF |
SMF |
SMF |
|
Operating Temperature |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
|
Part Number |
FT-SFP-0340D |
FT-SFP-0380D |
FT-SFP-03100D |
FT-SFP-03120D |
FT-SFP-03150D |
|
Image |
|
|
|
|
|
|
Max. Data Rate |
1.25Gbps |
1.25Gbps |
1.25Gbps |
1.25Gbps |
1.25Gbps |
|
Wavelength |
1550nm |
1550nm |
1550nm |
1550nm |
1550nm |
|
Max Distance |
40km |
80km |
100km |
120km |
150km |
|
Connector |
LC Duplex |
LC Duplex |
LC Duplex |
LC Duplex |
LC Duplex |
|
Media |
SMF |
SMF |
SMF |
SMF |
SMF |
|
Operating Temperature |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
0~70°C / -45~+85℃ |
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
