1.25Gbps GbE/FC 1310nm Multi-mode Dual LC 2km SFP Transceiver Module
1.25Gbps GbE/FC 1310nm Multi-mode Dual LC 2km SFP Transceiver Module
- Operating data rate up to 1.25Gbps
- 1310nm FP laser transmitter
- Up to 2km with 50/125μm MMF
- Single 3.3V power supply and TTL Logic Interface
- Hot-pluggable SFP footprint duplex LC connector interface
- Compliant with SFP MSA
- Class 1 FDA and IEC60825-1 laser safety compliant
- Part Number: S1G13-2
- Device Type: SFP LXM
- Package: SFP
- Data Rate: 1.25/1.0625Gbps
- Wavelength: 1310nm
- Distance/Power Budget: 2km
- Optical Components
- LD: FP
- PD: PIN
- Output Power: -9.5~-3dBm
- Receiver Sensitivity: -20dBm
- Power Supply Voltage: 3.3V
- Connector: Dual LC
- Fiber Type: MMF
- Operating Temperature: 0~70/ -10~80/ -40~85 °C
- DDMI: With/ Without
- Application: GBE /FC /FTTx
- Compatiblity: All Brands
F-tone is the original manufacturer of SFP LXM S1G13-2 - 1.25Gbps GbE/FC 1310nm Multi-mode Dual LC 2km SFP Transceiver Module. We have ready stock for S1G13-2 and can ship it out in two business days. We guarantee the S1G13-2 transceiver module to work in your system and all of our S1G13-2 transceiver modules come with a lifetime warranty.
The S1G13-2 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S1G13-2 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
