1.25Gbps GbE/FC 850nm Multi-mode Dual LC 550m SFP Transceiver Module
1.25Gbps GbE/FC 850nm Multi-mode Dual LC 550m SFP Transceiver Module
- Hot-Pluggable SFP Footprint LC Optical Transceiver
- Small Form-Factor Pluggable (SFP) MSA compatible
- Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-SX
- Compliant with Fiber Channel FC-PH-2 for 100-M5-SN-1 and 100-M6-SN-1
- 850 nm(VCSEL) transmitter
- 300 m links with 62.5/125 mm MMF Cables
- 500 m links with 50/125 mmMMF Cables
- AC/AC Coupling according to MSA
- Single +3.3 V Power Supply
- RoHS Compliant
- Part Number: S1G85-05
- Device Type: SFP SX
- Package: SFP
- Data Rate: 1.25/1.0625Gbps
- Wavelength: 850nm
- Distance/Power Budget: 550m
- Optical Components
- LD: VCSEL
- PD: PIN
- Output Power: -9~-4dBm
- Receiver Sensitivity: -17dBm
- Power Supply Voltage: 3.3V
- Connector: Dual LC
- Fiber Type: MMF
- Operating Temperature: 0~70/ -10~80/ -40~85 °C
- DDMI: With/ Without
- Application: Ethernet/FC
- Compatiblity: All Brands
F-tone is the original manufacturer of SFP SX S1G85-05 - 1.25Gbps GbE/FC 850nm Multi-mode Dual LC 550m SFP Transceiver Module. We have ready stock for S1G85-05 and can ship it out in two business days. We guarantee the S1G85-05 transceiver module to work in your system and all of our S1G85-05 transceiver modules come with a lifetime warranty.
The S1G85-05 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S1G85-05 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
