1.25Gbps Single-mode Dual LC 28dB Power Budget 100km DWDM SFP Transceiver Module
1.25Gbps Single-mode Dual LC 28dB Power Budget 100km DWDM SFP Transceiver Module
- Operating Data Rate up to 1.25Gbps
- Available in all C-Band Wavelengths on the 100GHz DWDM ITU Grid
- Single 3.3V Power Supply and TTL Logic Interface
- Hot-Pluggable SFP Footprint Duplex LC Connector Interface
- Compliant with Class 1 FDA and IEC60825-1 Laser Safety
- Compliant with SFP MSA
- Part Number: S1GDW-28
- Device Type: GE DWDM SFP
- Package: SFP
- Data Rate: 1.25Gbps
- Wavelength: 100GHz DWDM
- Distance/Power Budget: 100km/28dB
- Optical Components
- LD: DFB
- PD: PIN
- Output Power: 0~5dBm
- Receiver Sensitivity: -28dBm
- Power Supply Voltage: 3.3V
- Connector: Duel LC
- Fiber Type: SMF
- Operating Temperature: 0~70/ -10~80/ -40~85 °C
- DDMI: With/ Without
- Application: Ethernet/ DWDM
- Compatiblity: All Brands
F-tone is the original manufacturer of GE DWDM SFP S1GDW-28 - 1.25Gbps Single-mode Dual LC 28dB Power Budget 100km DWDM SFP Transceiver Module. We have ready stock for S1GDW-28 and can ship it out in two business days. We guarantee the S1GDW-28 transceiver module to work in your system and all of our S1GDW-28 transceiver modules come with a lifetime warranty.
The S1GDW-28 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S1GDW-28 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
