10/100/1000M Gigabit Ethernet Singlemode Single-Fiber BiDi Media Converter
10/100/1000M Gigabit Ethernet Singlemode Single-Fiber BiDi Media Converter
10/100/1000M Gigabit Ethernet Singlemode Single Fiber BiDi Standalone Media Converter
The SA-GEA-SM-B series Gigabit Ethernet fiber media converters comply with IEEE 802.3/ab Gigabit Ethernet standard. It supports two types of media for network connection such as 10/100/1000 Base-T to 1000 Base SX/LX/EX/ZX and connects these two types of segments to operate smoothly. SA-GEA-SM series can be used in 14 slot chassis as plug in module. The Fiber Media Converter transforms 1000Base-T (Copper Gigabit) media to 1000Base-SX/LX/EX/ZX (Fiber Gigabit) media and vice versa. The 1000Base-T port supports full-duplex Gigabit connection at wire speed with RJ45 connector. The fiber Gigabit connection supports shortwave (SX) or long wave (LX) laser optic with multi-mode or single-mode.
10/100/1000 means, that media converter that converts the electrical signal of a 10/100/1000 Ethernet signal from copper to fiber. This solution will offer a low-cost integration option for network managers who want to migrate from 10/100 networks to Gigabit Ethernet. Gigabit only switches can now be connected to 10/100 networks without the need to upgrade the 10/100 side, allowing network managers to add new equipment gradually.
Features
- Compliant with IEEE 1000Base-T and 1000Base-LX
- One 10/100/1000Base-T RJ-45 port autosensing featured!
- One 1000Base-LX/SX Port with SC/ST/FC Type Connector
- Status LED indicators for Power, Link/Activity, Full-Duplex, and Speed
- Wall-Mountable, pluggable in universal chassis, or desktop
- Available in SingleFiber WDM versions - 1310/1550 nm wavelenghts used
- Standards: IEEE802.3z/ab 1000Base-T 1000Base-SX/LX
- LED Indicators: FX LINK, FX FDX, TP LINK, TP FDX, ACT, POWER
- Data rate: 2000Mbps full duplex
- TP: 1000 FDX with NWAY auto-negotiation
Specifications
- Wavelength: Single-mode 1310nm, 1550nm
- Fiber cable(m): 8.3/125, 8.7/125, 9/125 or 10/125 single-mode
- Maximum distance: Multimode;550m Single-mode;20km/40km/60km/80km/100km/120km
- Power supply: External, Built-in, USB
- Dimensions: 81mm(L)X105mm(W)X26.2mm(H)
-
Environment
- Relative humidity: 5% to 90%
- Operating temperature: 0 to 70
- Storage temperature: -20 to 85
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
