10/100M Fast Ethernet 1 FE SFP port & 1 RJ45 port SFP Media Converter
10/100M Fast Ethernet 1 FE SFP port & 1 RJ45 port SFP Media Converter
This SFP Media Converter is an Ethernet media converter that converts media transmission between UTP Copper cables and fiber SFP (Small Form-Factor Pluggable) transceivers.
This series SFP media converters are designed to meet the massive needs for Ethernet network deployment and able to extend a copper based Gigabit network via fiber cable to a maximum distance up to 120km.
The series SFP media converters are fully compliant with IEEE802.3z & 802.3ab standards. It can be installed into a Standard Converter Chassis. The installation & operation procedures are simple & straight forward. Operation status can be locally monitored through a set of Diagnostic LED located in the front panel.
Features
- Conversion between different transmission speeds and media types
- Standalone and compact hardware design
- Auto-negotiating Ethernet port (Half/Full Duplex)
- Auto-crossover Ethernet port (Supports Auto MDI/MDI-X)
- Plug-and-Play installation
- Built-in Link Loss Forwarding Technology
- Easy Installation, Easy Trouble shooting
Specifications
-
Standard Compliance
- IEEE802.3 10BASE-T
- IEEE802.3u 100BASE-TX
- IEEE 802.3z 100Base- SX/LX standards
- IEEE802.3x Flow Control and Back pressure
-
Connector and Interface
- Fiber: FE SFP
- Copper: RJ45 (10/100Mbps)
- MDI/MDI-X and Auto-Negotiation Function Support
- LED Indication: FEF,SPD,FX-LINK,TX-LINK,PWR,FDX
- Power: External power supply
- Dimension: 95 ×70 ×26mm(out) power external
Link Loose Forward
- TX to Fiber: If TX port link is broken, then the media converter will force the fiber to link down.
- Fiber to TX: If Fiber port link is broken,the media converter will force the TX port to link down.
DIP Switch
- DIP Switch 1: Fiber Auto-Negotiation/100Mbps FulDuplex mode
- DIP Switch 2: TX to Fiber LLF (Link LoseForwarding) Disable/Enable
- DIP Switch 3: Fiber to TX LLF (Link LoseForwarding) Disable/Enable
Operation Environment
- Operating temperature: 0°C ~ 70°C
- Storage temperature: -40°C~ 85°C
- Operating humidity: 10% ~ 90%, non-condensing
The 10/100 Fast Ethernet Media Converter supports industry standard FE SFPs.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
