10/100M Fast Ethernet 1 FX port & 7 RJ45 port Single-Fiber BiDi Mini Fiber Switch

10/100M Fast Ethernet 1 FX port & 7 RJ45 port Single Fiber BiDi Standalone Media Converter (Fiber Switch)

SA-FE-1F7T Series provides one 100M optical fiber port and seven10/100M UTP ports. The Fast Ethernet fiber switch is possessed of stable performance, excellent quality and reasonable price.

Features

• With one fiber and seven UTP ports, SA-FE-1F7T can convert Optical－Electric Ethernet signals between 10/100M UTP interface (TX) and 100M optical fiber interface (FX).
• Auto negotiation function allows UTP port to auto select 10M or 100M, and Full Duplex or Half Duplex.
• Support Flow control and Broadcast storm protection
• Supporting the max 1536 bytes frame
• Internal Circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.

Specifications

• Operating standards: IEEE802.3u 100Base-TX and 100Base-FX
• Connector:
  • UTP: 7 x RJ-45,10/100Mbps;
  • Fiber: 1 x Simplex SC/FC/ST,100Mbps (Full Duplex)
• Cable
  • UTP cable: Cat. 5 (the max distance up to 100m)
  • Fiber (multimode): 50/125, 62.5/125μm(the max distance up to 2km)
  • Fiber (singlemode): 8/125, 8.7/125, 9/125, 10/125μm (the max distance up to 120km)
• Flow control
  • Full Duplex: IEEE802.3x flow control
  • Half Duplex: bake pressure flow control
• LED Light: PWR, FX Link/Act, TP1 FDX,TP1 Link/Act, TP2 FDX, TP2 Link/Act
• Power supply： AC100 ～ 240V, DC5V 1A;
• Work Circumstance:
  • Environment temperature：0 ～ +50℃
  • Storage temperature:：：-20 ～ +70℃
  • Humidity:：5% ～ 90%
