1000M Gigabit Ethernet Multimode 1310nm 2km Media Converter

The 1000M Gigabit Fiber Media Converter can convert Optical－Electric Ethernet signals between 1000M UTP interface (1000BASE-T) and 1000M optical fiber interface（1000BASE-X）. The traditional 1000M Gigabit Ethernet can be extended to the distance of 100km through optical fiber link.

6 Group LED indicated lights could fully monitor the working conditions of converters. It is easy for users to observe and diagnose the failure of converters. The Series Gigabit Converters could be used individual, or inserted to 14 slots RACK which is suitable for the use of Network Centre.

Features & Specifications

• Supports only 1000M and Full Duplex.
• The UTP port supports the connection of MDI-MDIX auto crossover.
• Small power consumption, less heat, small size
• Operating standards:  IEEE802.3z/AB, 1000Base-T and 1000Base-SX
• Connector: UTP: RJ45, 1000Mbps;  Fiber: SC/ST/FC,1000Mbps
• Fiber Type: Multimode
• Wavelength: 1310nm
• Max Distance: 2km
• Cable :
  • UTP cable: Cat 5e or Cat 6 (the max distance up to 100m)
  • Fiber : multimode : 50/125, 62.5/125μm (the max distance up to 2km)
• LED：PWR ，FX Link/Act，TP TX，TP RX，TP 100，TP 1000
• Power:  AC 110 ～ 240V to DC 5V; DC48V to DC 5V.
• Ambient temperature：0 ～ +50℃
• Storage temperature：-20 ～ +70℃
• Humidity：5% ～ 90%
• Dimensions：26 (high) × 70 (width) × 93 (length) mm
