10Gbps 850nm Multimode Dual SC 300m X2 Transceiver Module with DDMI
10Gbps 850nm Multimode Dual SC 300m X2 Transceiver Module with DDMI
- Hot pluggable X2 MSA form factor
- Low total power consumption:
- RoHS-6 compliant (lead-free)
- 850nm VCSEL
- Transmission distance 300m
- SC connector,multi-mode fiber
- Full duplex transmission mode
- Digital Optics Monitoring (DOM)
- Power supply: +5.0 V, +3.3 V
- XAUI electrical interface 4 x 3.125 Gb/s Ethernet(FTLX1841E2)
- Management and control via MDIO 2-wire bus
- 70-pin connector
- Separated signal/chassis ground
- Mid Pak module variance for front panel mounting
- De-latch mechanism with low extraction force
- Part Number: X285-03D
- Device Type: X2 SR
- Package: X2
- Data Rate: 10.3Gbps
- Wavelength: 850nm
- Distance/Power Budget: 300m
- Optical Components
- LD: VCSEL
- PD: PIN
- Output Power: -6~-1dBm
- Receiver Sensitivity: -10dBm
- Power Supply Voltage: 1.2V/ 3.3V
- Connector: Dual SC
- Fiber Type: MMF
- Operating Temperature: 0~70 °C
- DDMI: With
- Application: Ethernet/ 10G FC
- Compatiblity: All Brands
F-tone is the original manufacturer of X2 SR X285-03D - 10Gbps 850nm Multimode Dual SC 300m X2 Transceiver Module with DDMI. We have ready stock for X285-03D and can ship it out in two business days. We guarantee the X285-03D transceiver module to work in your system and all of our X285-03D transceiver modules come with a lifetime warranty.
The X285-03D is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The X285-03D must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
