1G Dual-Port SFP Intel I350-AM2 Ethernet Network Interface Card-F-tone

Name: 1G Dual-Port SFP Intel I350-AM2 Ethernet Network Interface Card-F-tone
Brand: F-tone
SKU: FT-100609
Price: 99.99 CNY
Availability: InStock

Transceivers Type

SFP Optical Transceiver

Compatible

Mainstream Servers

Specifications

1G Dual Port SFP Intel I350-AM2 Ethernet Network Interface Card

The network interface card (NIC) with 2×1Gb ports is built on the Intel I350-AM2 controller to enhance server connectivity and network virtualization. The adapter utilizes a PCIe 2.0 X 4 host interface, providing ample bandwidth for line rate traffic on 1Gb ports. The NIC offers enhanced virtualization capabilities, making it an ideal choice for virtualized environments. Its design ensures broad interoperability, optimized performance, and improved flexibility for enterprise IT, cloud, and communication network solutions.

Ports	Dual	Controller	Intel I350-AM2
Supported Ethernet Speeds	1G	Host Interface	PCIe 2.0 X 4
Cabling Type	SFP Transceiver, AOC and DAC	Link Rate	5.0 GT/s
Connectivity (VT-c)	Yes	OS Support	Windows, Linux, VMware, FreeBSD
Bracket Height	Half & Full	Max. Power Consumption	3.3w
Storage Humidity	90% max. non-condensing relative humidity at 35ºC	Storage Temperature	-40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity	85% max. non-condensing relative humidity	Operating Temperature	0 °C to 55 °C (32 °F to 131 °F)
Card PCB Dimensions (WxD)	12868.11.6mm	RoHS R6 Compliant	Yes

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

View full details

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.

about us Contact Us

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing
