2.125Gbps 2X/1X Fiber Channel 1550nm Dual LC Singl-mode 40km SFP Optical Transceiver Module

2.125Gbps 2X/1X Fiber Channel 1550nm Dual LC Singl-mode 40km SFP Optical Transceiver Module

Description

Features Hot-Pluggable SFP Footprint LC Optical Transceiver Small Form-Factor Pluggable (SFP) MSA compatible Compliant with Fiber Channel 1X/2X SM-LC-L FC-PI Compliant with IEEE 802.3z Gigabit Ethernet 1550 nm DFB LD Transmitter Distance up to 40 km AC/AC Coupling according to MSA Single +3.3 V Power Supply RoHS Compliant Class 1 Laser International Safety Standard IEC-60825 Compliant Specifications Part Number: S2G15-40 Device Type: FC SFP Package: SFP Data Rate: 2.125/1.0625Gbps Wavelength: 1550nm Distance/Power Budget: 40km Optical Components LD: DFB PD: PIN Output Power: 0~5dBm Receiver Sensitivity: -21/-22dBm Power Supply Voltage: 3.3V Connector: Dual LC Fiber Type: SMF Operating Temperature: 0~70/ -10~80/ -40~85 °C DDMI: With/ Without Application: Multi-rate FC Compatiblity: All Brands F-tone is the original manufacturer of FC SFP S2G15-40 - 2.125Gbps 2X/1X Fiber Channel 1550nm Dual LC Singl-mode 40km SFP Optical Transceiver Module. We have ready stock for S2G15-40 and can ship it out in two business days. We guarantee the S2G15-40 transceiver module to work in your system and all of our S2G15-40 transceiver modules come with a lifetime warranty. The S2G15-40 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S2G15-40 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

These generic SFP transceivers are programmed to be compatible with a wide variety of switch brands. If you need specific switch brand compatibility, we offer custom labeling options including your company name, logo, part number, serial number, and barcode.

Please contact us to discuss your specific requirements.

Important Notice

Every module is tested before shipment. If you need a datasheet for this product or can't find a compatible module from us, please contact us. We also provide a wide variety of OEM/ODM solutions.

View full details

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.

about usContact Us

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
