2.5Gbps OC-48/STM-16 SDH/SONET 1310nm Single-mode Dual LC 2km SFP Transceiver Module

Name: 2.5Gbps OC-48/STM-16 SDH/SONET 1310nm Single-mode Dual LC 2km SFP Transceiver Module
Brand: F-tone Networks
Price: 75.00 CNY
Availability: InStock

Description

Features Hot-Pluggable SFP Footprint LC Optical Transceiver Small Form-Factor Pluggable (SFP) MSA compatible Compliant with Intra-Office SONET OC-48 SR / SDH STM-16 (I-16) Compliant with Fibre Channel 1x/2x SM-LC-L FC-PI Compliant with IEEE 802.3z 1000BASE-LX operates at a nominal wavelength of 1310 nm Distance Up to 2 km AC/AC Coupling according to MSA Single +3.3 V Power Supply RoHS Compliant Class 1 Laser International Safety Standard IEC-60825 Compliant Specifications Part Number: S4813-2 Device Type: OC48 SFP Package: SFP Data Rate: 2.5Gbps Wavelength: 1310nm Distance/Power Budget: 2km Optical Components LD: FP PD: PIN Output Power: -9~-3dBm Receiver Sensitivity: -18dBm Power Supply Voltage: 3.3V Connector: Dual LC Fiber Type: SMF Operating Temperature: 0~70/ -10~80/ -40~85 °C DDMI: With/ Without Application: GE/ SONET/ SDH/ FC Compatiblity: All Brands F-tone is the original manufacturer of OC48 SFP S4813-2 - 2.5Gbps OC-48/STM-16 SDH/SONET 1310nm Single-mode Dual LC 2km SFP Transceiver Module. We have ready stock for S4813-2 and can ship it out in two business days. We guarantee the S4813-2 transceiver module to work in your system and all of our S4813-2 transceiver modules come with a lifetime warranty. The S4813-2 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S4813-2 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

These generic SFP transceivers are programmed to be compatible with a wide variety of switch brands. If you need specific switch brand compatibility, we offer custom labeling options including your company name, logo, part number, serial number, and barcode.

Please contact us to discuss your specific requirements.

Important Notice

Every module is tested before shipment. If you need a datasheet for this product or can't find a compatible module from us, please contact us. We also provide a wide variety of OEM/ODM solutions.

View full details

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.

about us Contact Us

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing
