4K HDMI Active Optical Cable (Support ARC)

Name: 4K HDMI Active Optical Cable (Support ARC)
Brand: 我的商店
Availability: InStock

Product Details
In 4K UHD era, high resolution and high frame rate images require better wire transmission. High bandwidth and low latency have become necessary characteristics of high-quality HDMI cables.
F-tone Networks' FT-62-H2C07 product is an 4K HDMI optical cable with 32Gbps bandwidth and ARC function. It adopts BendRobust® special bending-resistant optical fiber, which is exclusive to YOFC. The connector is newly designed with metal shielding shell, which brings larger bandwidth and better shielding effect, and ensures high-speed and stable signal transmission in complex electromagnetic environment.

Applications
● Home Theaters
● Living Room Entertainment
● Large Exhibition Halls
● Performance Halls

Specifications

Product Model	FT-62-H2C07
Cable Length	up to 20m
Connector	HDMI Type-A Connector-HDMI Type-A Connector, Black injection mold
Bandwidth	32Gbps, support 4K@60Hz UHD display, support ARC
Power Supply	No external power needed
Power Consumption	700mw
Housing Material	Black TPE
Mechanical/Condition	Cable Diameter, 4.6mm Bend Radius (Dynamic/Static), 20mm/10mm Tensile Strength (Long term/Short term), 100N/200N Crush Resistance (Long term/Short term), 200N/400N Operating/Storage Temperature, -20~70°C / -40~85°C Operating/Storage Humidity, 0~85% / 0~85% Note: It is recommended to use this active optical cable with the resolution higher than 1080i.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
