Cisco CWDM-SFP+-ZR-1510 Compatible 10G 1510nm CWDM SFP+ 80km DDM LC SMF Transceiver

Cisco CWDM-SFP+-ZR-1510 Compatible 10G 1510nm CWDM SFP+ 80km DDM LC SMF Transceiver

Cisco CWDM-SFP10G-1510-80 Compatible 10G CWDM SFP+ Transceiver Module (SMF, 1510nm, 80km, LC, DOM)

The CWDM-SFP10G-ZR series SFP+ optical transceiver is equipped with an LC duplex connector, reaching a link up to 80km over G.652/655. This 10G CWDM SFP+ transceiver, operating at a CWDM wavelength from 1470nm to 1610nm as specified by the ITU-T, is designed to deploy in the CWDM networking equipment in metropolitan access networks or long-haul networks. F-tone manufactured 10GBASE-CWDM SFP+ transceiver module is complaint with the SFF-8431 MSA and SFF8432 MSA. It's also fully compatible with almost all Cisco devices.

Model Name: CWDM-SFP10G-1510-80 Vendor Name: F-tone
Form Factor: SFP+ Data Rate: 9.95 to 11.3Gb/s bit rates
Wavelength: 1510nm Distance: 80km@G.652
Connector: LC Duplex Cable Type: OS2 SMF
Transmitter Type: EML Receiver Type: APD
TX Power: 0~+5dBm Receiver Sensitivity: <-24dBm
Power Consupumtion: <1.5W Modulation Format: NRZ
DDM: Support Bit Error Ratio (BER): 1.00E-12
Protocols: IEEE 802.3ae, SFF-8472 Warranty: 5 Years



Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

View full details

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.

about usContact Us

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing

End Face Testing

Check the end face of the transceivers and keep them clean for more stable data transmission, better performance, and durability.

End Face Testing

Various Switch Tests

Every module is quality tested for compatibility in the multi-brand switches environment, guaranteeing flawless operations.

Various Switch Tests
