DWDM High Power Source

Name: DWDM High Power Source
Brand: 我的商店
Availability: InStock

Features
● DT14, 14 Pin butterfly package
● Laser cooled, wavelengthstable
● Built in monitor photodiode（ MPD ）
● Low RIN -165dB/Hz ◆ High power
● DWDM wavelength
Applications
● Optical Source
● CATV
● Test and measurement
Absolute Maximum Ratings

Electrical and Optical Characteristics (@25°C)Fiber SpecificationNote（1）：Another optical connector available upon request.
Electrical Schematic
Mechanical Drawing and Pin Definitions Heat Dissipation Requirements
In order to ensure proper performance, heat sinking and heat removal must be provided by the user to limit maximum temperature of the device.

Ordering InformationNote（2:)Recommend 155 (1550+/-10nm), DWDM wavelength available upon request.
（3)：80mW/100mW/120mW version only available for-20 C~50 C case temperature.

lmportant Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
