F-tone 1G SFP CWDM 1290nm 40km

Name: F-tone 1G SFP CWDM 1290nm 40km
Brand: F-tone Networks
Availability: InStock

F-tone Networks is the original manufacturer of 1.25G CWDM SFP - 1.25Gbps Single-mode Dual LC 19dB Power Budget 40km CWDM SFP Transceiver Module with 1290nm wavelength. We have ready stock for this product and can ship it out in two business days. We guarantee this transceiver module to work in your system and all of our transceiver modules come with a lifetime warranty.

This is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. This module must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-XD
18 Wavelength (λ): 1270nm to 1610nm CWDM DFB LD Transmitter
19 dB Power Budget at Least
AC/AC Coupling according to MSA
Single +3.3 V Power Supply
RoHS Compliant
Class 1 Laser International Safety Standard IEC-60825 Compliant

Specifications

Parameter	Value	Parameter	Value
Part Number	F-tone-1GCW-19-1290	Device Type	1.25G CWDM SFP
Package	SFP	Data Rate	1.25/1.0625Gbps
Wavelength	1290nm (Selectable 1270nm~1610nm)	Distance/Power Budget	40km/19dB
LD Type	DFB	PD Type	PIN
Output Power	-5~0dBm	Receiver Sensitivity	-24dBm
Power Supply	3.3V	Connector	Dual LC
Fiber Type	SMF	Operating Temperature	0~70°C / -10~80°C
DDMI	With/Without	Application	GBE/FC/FTTx
Compatibility	All Major Brands

Contact Information

7×24 Phone	+86 177 6116 3895
Email	una@f-tone.com
Whatsapp	+86 177 6116 3895
VK ID	qsfposfp
Wechat ID	F-tone027
Support	support@f-tone.com
Facebook	william@f-tone.com
Skype ID	william@f-tone.com
Russian Site	https://www.qsfposfp.ru
English Site	https://www.qsfposfp.com
Chinese Site	https://www.f-tone.com
Address	F-tone Building, Digital Economy Industrial Park, Tianfu New Area, Sichuan, China

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
