F-tone FTJG16740B4NL 100/1000 Base-T Single Port RJ45 Gigabit Magnetic Jack Tab Up Yellow&Green/Green Leds

Product Details

Parameter	Value
Compatible Brands	F-tone
Application - LAN	ETHERNET (NON PoE)
Temperature	-40℃ to +85℃
Latch	Up
Pin Type	THT SOLDER
LED Option	Yellow&Green / Green
Shield EMI Tabs	NO
Speed	1000 Base-T
Manufacture	F-tone
L/T(In stock)	5-7 days
L/T(out of stock)	4-6 weeks

Description

The FTJG16740B4NL supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Digital Camera, Router, Automation and Network Firewall.

Parameter	Value	Parameter	Value
F-tone Part Number	FTJG16740B4NL	Connector Type	Jack
Part Status	Active	Mounting Type	Through Hole
Number of Positions/Contacts	10p8c (RJ45, Ethernet)	Application-Lan	Ethernet( NoN PoE )
Number of Ports	1x1 Port	Speed	10/100/1000 Base-T
Latch	UP	Cores per Port	8
Orientation	90° Angle (Right)	PCB Mount Angle	SIDE ENTRY
Shield EMI Tabs	Without	LED Option	Yellow&Green/Green
PCB	FR4	PCB Retaining Post	T POST
Package Height (Inches/mm)	0.530/13.45	Package Length (Inches/mm)	0.844/21.43
Package Width (Inches/mm)	0.635/16.12	Temperature	-40℃ TO 85℃
Bst Circuit	Yes	AutomDX	YES
Diodes	No	Contact Mating Area Plating	GOLD 6u"/15u"/30u"
Turns Ratio RX/TX	1CT:1CT	Configuration RX/TX	T,C

Packaging Details

N.W/pcs: 0.008kg
Package: Tray
SPQ: 50pcs
Qty/carton: 1200pcs
Carton size: 32*30*31cm
G.W/carton: 9kg

Contact Information

7×24 Phone：+86 177 6116 3895
Email：una@f-tone.com
Whatsapp：+86 177 6116 3895
VK ID：qsfposfp
Wechat ID：F-tone027
support：support@f-tone.com
Facebook：william@f-tone.com
Skype ID：william@f-tone.com
English Site：https://www.qsfposfp.com
Russian Site：https://www.qsfposfp.ru
Chinese Site：https://www.f-tone.com
Address：F-tone Building, Digital Economy Industrial Park, Tianfu New Area, Sichuan, China

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
