F-tone S1213-40 622Mbps OC-12/STM-4 SDH/SONET 1310nm Single-mode Dual LC 40km SFP Transceiver Module

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with SONET OC-12 LR-1 / SDH STM-4(L-4.1)
1310 nm Transmitter, single-mode fiber
0 to 40000 m Transmission
AC/AC Coupling according to MSA
Single +3.3 V Power Supply
RoHS Compliant

Specifications

Parameter	Value
Part Number	S1213-40
Device Type	OC12 SFP
Package	SFP
Data Rate	622Mbps
Wavelength	1310nm
Distance/Power Budget	40km
Optical Components LD	DFB
Optical Components PD	PIN
Output Power	-5~0dBm
Receiver Sensitivity	-30dBm
Power Supply Voltage	3.3V
Connector	Dual LC
Fiber Type	SMF
Operating Temperature	0~70/ -10~80/ -40~85 °C
DDMI	With/ Without
Application	FE/ SDH/ SONET/ FTTx
Compatibility	All Brands

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Email us your design if you choose customised labels.

F-tone is the original manufacturer of OC12 SFP S1213-40 - 622Mbps OC-12/STM-4 SDH/SONET 1310nm Single-mode Dual LC 40km SFP Transceiver Module. We have ready stock for S1213-40 and can ship it out in two business days. We guarantee the S1213-40 transceiver module to work in your system and all of our S1213-40 transceiver modules come with a lifetime warranty.

The S1213-40 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S1213-40 must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
