F-tone S1G15-120 - 1.25Gbps GbE/FC 1550nm Single-mode Dual LC 120km SFP Transceiver Module

Description

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with IEEE 802.3z 1000BASE-ZX
Compliant with Fibre Channel 1x SM-LC-L FC-PI
1550 nm DFB LD Transmitter
APD High Sensitivity Receiver
32 dB Power Budget at Least
Distance up to 120 km
Single +3.3 V Power Supply
RoHS Compliant
Class 1 Laser International Safety Standard IEC-60825 Compliant

Specifications

Parameter	Value
Part Number	F-tone S1G15-120
Device Type	SFP EZX
Package	SFP
Data Rate	1.25/1.0625Gbps
Wavelength	1550nm
Distance/Power Budget	120km
Optical Components	LD: DFB PD: APD
Output Power	0~5dBm
Receiver Sensitivity	-32dBm
Power Supply Voltage	3.3V
Connector	Dual LC
Fiber Type	SMF
Operating Temperature	0~70/ -10~80/ -40~85 °C
DDMI	With/ Without
Application	GBE /FC /FTTx
Compatiblity	All Brands

F-tone is the original manufacturer of SFP EZX F-tone S1G15-120 - 1.25Gbps GbE/FC 1550nm Single-mode Dual LC 120km SFP Transceiver Module. We have ready stock for F-tone S1G15-120 and can ship it out in two business days. We guarantee the F-tone S1G15-120 transceiver module to work in your system and all of our F-tone S1G15-120 transceiver modules come with a lifetime warranty.

The F-tone S1G15-120 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The F-tone S1G15-120 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.

View full details

About F-tone Networks

F-tone Networks is now a world leader in development of optical transceivers and provide a wide range of high-speed optical solutions for optical communication networking, especially for AI, Data Center, enterprise data networking, Industry, aerospace, mining, shipbuilding, railway, metro, long haul transport networking, and mobile access networking applications
F-tone Networks invested in foundational photonics technologies and extensive product development and engineering with global presence in many area also.

about us Contact Us

Power and Wavelength Testing

Test the signal delivering strength and wavelength, to ensure the signal decoding capacity of the receiver, and the wavelength remains consistent from the transmitter to the receiver.

Power and Wavelength Testing

Traffic Testing

Test the bit error rate and packet loss rate, to make them meet the corresponding standards and ensure the performance of transceivers.

Traffic Testing

Optical Performance Testing

Test the transceivers' eye diagram situation, receiving sensitivity, extinction ratio, wavelength, light-emitting, light-receiving, current and voltage, to ensure the signal quality, stability and reliability of the transmission.

Optical Performance Testing
