F-tone S1G85-05 - 1.25Gbps GbE/FC 850nm Multi-mode Dual LC 550m SFP Transceiver Module

Description

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with IEEE 802.3z Gigabit Ethernet 1000BASE-SX
Compliant with Fiber Channel FC-PH-2 for 100-M5-SN-1 and 100-M6-SN-1
850 nm(VCSEL) transmitter
300 m links with 62.5/125 mm MMF Cables
500 m links with 50/125 mmMMF Cables
AC/AC Coupling according to MSA
Single +3.3 V Power Supply
RoHS Compliant

Specifications

Parameter	Value
Part Number	F-tone S1G85-05
Device Type	SFP SX
Package	SFP
Data Rate	1.25/1.0625Gbps
Wavelength	850nm
Distance/Power Budget	550m
Optical Components	LD: VCSEL PD: PIN
Output Power	-9~-4dBm
Receiver Sensitivity	-17dBm
Power Supply Voltage	3.3V
Connector	Dual LC
Fiber Type	MMF
Operating Temperature	0~70/ -10~80/ -40~85 °C
DDMI	With/ Without
Application	Ethernet/FC
Compatiblity	All Brands

F-tone is the original manufacturer of SFP SX F-tone S1G85-05 - 1.25Gbps GbE/FC 850nm Multi-mode Dual LC 550m SFP Transceiver Module. We have ready stock for F-tone S1G85-05 and can ship it out in two business days. We guarantee the F-tone S1G85-05 transceiver module to work in your system and all of our F-tone S1G85-05 transceiver modules come with a lifetime warranty.

The F-tone S1G85-05 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The F-tone S1G85-05 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
