F-tone S2G13-10 - 2.125Gbps 2X/1X Fiber Channel 1310nm Dual LC Single-mode 10km SFP Optical Transceiver Module

Description

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with Fibre Channel 1X/2X SM-LC-L FC-PI
Compliant with IEEE 802.3z 1000BASE-LX
1310 nm LD Transmitter
Distance up to 10 km
AC/AC Coupling according to MSA
Single +3.3 V Power Supply
RoHS Compliant
Class 1 Laser International Safety Standard IEC-60825 Compliant

Specifications

Parameter	Value
Part Number	F-tone S2G13-10
Device Type	FC SFP
Package	SFP
Data Rate	2.125/1.0625Gbps
Wavelength	1310nm
Distance/Power Budget	10km
Optical Components	LD: DFB PD: PIN
Output Power	-8~-3dBm
Receiver Sensitivity	-21/-22dBm
Power Supply Voltage	3.3V
Connector	Dual LC
Fiber Type	SMF
Operating Temperature	0~70/ -10~80/ -40~85 °C
DDMI	With/ Without
Application	Multi-rate FC
Compatiblity	All Brands

F-tone is the original manufacturer of FC SFP F-tone S2G13-10 - 2.125Gbps 2X/1X Fiber Channel 1310nm Dual LC Single-mode 10km SFP Optical Transceiver Module. We have ready stock for F-tone S2G13-10 and can ship it out in two business days. We guarantee the F-tone S2G13-10 transceiver module to work in your system and all of our F-tone S2G13-10 transceiver modules come with a lifetime warranty.

The F-tone S2G13-10 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The F-tone S2G13-10 must be operatred within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
