HP J9150A Compatible X132 10G SFP+ SR Transceiver 850nm 300m LC

Specifications

Parameter	Value
Part Number	J9150A
Device Type	HP SFP+ SR Compatible
Package	SFP+
Data Rate	10.3Gbps
Wavelength	850nm
Distance	300m
Optical Components	LD: VCSEL, PD: PIN
Output Power	-6~-1dBm
Receiver Sensitivity	-11.1dBm
Power Supply	3.3V
Connector	Dual LC
Fiber Type	MMF
Operating Temperature	0~70°C
DDMI	With
Application	10G/10G FC
Compatibility	100% HP Compatible

Description

F-tone Networks is the original manufacturer of HP SFP+ SR J9150A - HP X132 10G SFP+ LC SR 850nm 300m Transceiver. We have ready stock for J9150A and can ship it out in two business days. We guarantee the J9150A transceiver module to work in your system and all of our J9150A transceiver modules come with a lifetime warranty.

The J9150A is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The J9150A must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
