Low-speed Transparent Transmission Module

Name: Low-speed Transparent Transmission Module
Brand: 我的商店
Availability: InStock

Features
● MINISFF package structure
● Available data rates include 0~100M and others
● Optional long-distance and short-distance transmission
● Optional DWDM 100G ITU GRID C-band wavelengths
● Peak-to-peak jitter of the combined optical transmitter and receiver modules is less than 60ps
● LVDS input and output

● Industrial temperature range

● RoHS compliant
Application
● Transparent transmission of RS232/485 and other low-speed buses

● Transmission of power control signals

Ordering Information

Model	Wavelength (nm)	Data Rate	Transmission Distance (km)	Digital Diagnostic	X
FTMF-DxxLC-10x	100GHZ DWDM	0~100M	10	N	E:Commercial grade I: Industrial grade M: Military grade
FTMF-C55LA-02x	1550 CWDM	0~20	2	N	E:Commercial grade I: Industrial grade M: Military grade
FTMF-DxxLB-80x	100GHZ DWDM	0~50M	80	/	E:Commercial grade I: Industrial grade M: Military grade

Mechanical Dimensions(mm)

Note: Undesignated tolerances: ±0.25mm

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
