S0313-2 - 125Mbps FE/OC3 SFP Transceiver 1310nm 2km LC MMF

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
1310 nm Transmitter, multi-mode fiber
0 to 2000 m Transmission
AC/AC Coupling according to MSA
LV-TTL TX Disable Input Signal
LV-TTL RX Loss of Signal Output
Single +3.3 V Power Supply
RoHS Compliant

Specifications

Parameter	Value
Part Number	S0313-2
Device Type	FE/OC3 SFP
Package	SFP
Data Rate	155/125Mbps
Wavelength	1310nm
Distance	2km
Optical Components	LD: FP, PD: PIN
Output Power	-19~-14dBm
Receiver Sensitivity	-32dBm
Power Supply	3.3V
Connector	Dual LC
Fiber Type	MMF
Operating Temperature	0~70°C (Commercial)
DDMI	With/Without
Application	FE/SDH/SONET/FTTx
Compatibility	All Brands

Description

F-tone Networks is the original manufacturer of FE/OC3 SFP S0313-2 - 125Mbps Fast Ethernet, 155Mbps OC-3/STM-1 SDH/SONET 1310nm Multi-mode Dual LC 2km SFP Transceiver Module. We have ready stock for S0313-2 and can ship it out in two business days. We guarantee the S0313-2 transceiver module to work in your system and all of our S0313-2 transceiver modules come with a lifetime warranty.

The S0313-2 is a Class 1 laser product. It fully complies with the multi-sourcing agreement (MSA) which enables it to work in all MSA compliant platforms. The S0313-2 must be operated within the specified temperature and voltage limits. The optical ports of the module shall be terminated with an optical connector or with a dust plug.

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.

The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
