S1G13-10 - 1.25Gbps GbE/FC SFP 1310nm 10km LC SMF LX

S1G13-10 - 1.25Gbps GbE/FC SFP 1310nm 10km LC SMF LX

Features

  • Hot-Pluggable SFP Footprint LC Optical Transceiver
  • Small Form-Factor Pluggable (SFP) MSA compatible
  • Compliant with IEEE 802.3z 1000BASE-LX
  • Compliant with Fibre Channel 1x SM-LC-L FC-PI
  • Distance up to 10 km
  • Single +3.3 V Power Supply
  • RoHS Compliant

Specifications

Parameter Value
Part Number S1G13-10
Device Type SFP LX
Data Rate 1.25/1.0625Gbps
Wavelength 1310nm
Distance 10km
Output Power -9.5~-3dBm
Receiver Sensitivity -20dBm
Fiber Type SMF

Labeling Options

  • F-tone Labels (Default)
  • Generic Labels
  • Customised Labels
  • No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract.
