S1G15-120 - 1.25Gbps GbE/FC SFP 1550nm 120km LC SMF EZX

Features

Hot-Pluggable SFP Footprint LC Optical Transceiver
Small Form-Factor Pluggable (SFP) MSA compatible
Compliant with IEEE 802.3z 1000BASE-ZX
1550 nm DFB LD Transmitter
APD High Sensitivity Receiver
32 dB Power Budget at Least
Distance up to 120 km
Single +3.3 V Power Supply

Specifications

Parameter	Value
Part Number	S1G15-120
Device Type	SFP EZX
Data Rate	1.25/1.0625Gbps
Wavelength	1550nm
Distance	120km
Output Power	0~5dBm
Receiver Sensitivity	-32dBm
Fiber Type	SMF

Labeling Options

F-tone Labels (Default)
Generic Labels
Customised Labels
No Labels

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract.
