ZLC Fiber and Electrical Mixed Connectors ZLC2G4D IP68 Waterproof Optical Fiber Connector

Key attributes
Industry-specific attributes

Type	Connector
Application	Audio & Video
Gender	Other

Other attributes

Place of Origin	Cheng Du, China
Brand Name	F-tone Networks
Model Number	ZLC2G4D
Material	Stainless Steel
Keywords	Waterproof Connector Ip68
MOQ	2pcs
Shipping by	Buyer's Choice
Temperature Range	-40~+85
IP rating	IP 67/IP68
Packing	PE Bag carton Box
Payment	T/T
Warranty	1 Year

Packaging and delivery

Selling Units:	Single item
Single package size:	10X10X5 cm
Single gross weight:	1.000 kg

Product descriptions from the supplier

ZLC WATERPROOF Series  Fiber optical connectors

Threaded connection structure, fast connection, easy to use
Ceramic pins and three keyways are used to achieve precise docking, and multiple tail changes are optional With "three prevention" performance, anti-rat bite, anti-electromagnetic interference, can adapt to ships, watertight and other harsh environment
Connectors are generally divided into plug and socket forms, and the socket can be installed on the chassis and bulkhead with narrow internal space; The plug is used to implement the plug
The connection  has good mechanical environmental performance
At present, there are 4 cores and 6 cores (photoelectric series can be combined according to customer needs, such as 2 fiber 2 electricity, 4 fiber 2 electricity, etc.)
The products are suitable for field data transmission command system, shipboard communication system, aerospace communication system and other equipment for optoelectrical transmission

ZLC  Series PRODUCT PARAMETER

Parameter	Index Requirement
Insertion Loss	single mode ≤0.75dB;multi mode ≤0.5dB
Working Temperature	-40℃~+85℃
Waterproof Level	IP67
Maintenance force of optical cable components	≥720N
Static water pressure	≤5Mpa
Salt spray property	500H

Important Notice

Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
